AH

AH drawing.png

Item No.	Boundary Dimensions（mm）							Lock Nut	N.Weight （kg)
Item No.	d1	d	B1	B2	G	G1	G2	Lock Nut	N.Weight （kg)
AH208	35	40	25	27	M45X1.5	6		KM09	0.08
AH308	35	40	29	32	M45X1.5	6		KM09	0.09
AH2308	35	40	40	43	M45X1.5	7		KM09	0.13
AH209	40	45	26	29	M50X1.5	6		KM10	0.10
AH309	40	45	31	34	M50X1.5	6		KM10	0.12
AH2309	40	45	44	47	M50X1.5	7		KM10	0.16
AH210	45	50	28	31	M55X2	7		KM11	0.12
AHX310	45	50	35	38	M55X2	7		KM11	0.13
AHX2310	45	50	50	53	M55X2	9		KM11	0.19
AH211	50	55	29	32	M60X2	7		KM12	0.16
AHX311	50	55	37	40	M60X2	7		KM12	0.17
AHX2311	50	55	54	57	M60X2	9		KM12	0.26
AH212	55	60	32	35	M65X2	8		KM13	0.17
AHX312	55	60	40	43	M65X2	8		KM13	0.19
AHX2312	55	60	58	61	M65X2	11		KM13	0.30
AH213	60	65	32.5	36	M75X2	8		KM15	0.24
AH313	60	65	42	45	M75X2	8		KM15	0.26
AH2313	60	65	61	64	M75X2	12		KM15	0.39
AH214	65	70	33.5	37	M80X2	8		KM16	0.26
AH314	65	70	43	47	M80X2	8		KM16	0.28
AHX2314	65	70	64	68	M80X2	12		KM16	0.45
AH215	70	75	34.5	38	M85X2	8		KM17	0.28
AH315	70	75	45	49	M85X2	8		KM17	0.31
AHX2315	70	75	68	72	M85X2	12		KM17	0.53
AH216	75	80	35.5	39	M90X2	8		KM18	0.31
AH316	75	80	48	52	M90X2	8		KM18	0.37
AHX2316	75	80	71	75	M90X2	12		KM18	0.57
AH217	80	85	38.5	42	M95X2	9		KM19	0.36
AHX317	80	85	52	56	M95X2	9		KM19	0.43
AHX2317	80	85	74	78	M95X2	13		KM19	0.65
AH218	85	90	40	44	M100X2	9		KM20	0.43
AHX318	85	90	53	57	M100X2	9		KM20	0.46
AHX2318	85	90	79	83	M100X2	14		KM20	0.76
AHX3218	85	90	63	67	M100X2	10		KM20	0.57
AH219	90	95	43	47	M105X2	10		KM21	0.49
AHX319	90	95	57	61	M105X2	10		KM21	0.54
AHX2319	90	95	85	89	M105X2	16		KM21	0.90
AH220	95	100	45	49	M110X2	10		KM22	0.53
AHX320	95	100	59	63	M110X2	10		KM22	0.58
AHX2320	95	100	90	94	M110X2	16		KM22	1.00
AHX3120	95	100	64	68	M110X2	11		KM22	0.66
AHX3220	95	100	73	77	M110X2	11		KM22	0.76
AH222	105	110	50	54	M120X2	11		KM24	0.65
AHX3220	105	110	63	67	M120X2	12		KM24	0.77
AHX2322	105	110	98	102	M125X2	16		KM25	1.35
AHX3122	105	110	68	72	M120X2	11		KM24	0.76
AHX3222	105	110	82	86	M125X2	11		KM25	1.05
AH24122	105	110	82	91	M115X2	13		KM23	0.71
AH224	115	120	53	57	M130X2	12		KM26	0.65
AHX324	115	120	69	73	M130X2	13		KM26	0.88
AHX2324	115	120	105	109	M135X2	17		KM27	1.65
AHX3024	115	120	60	64	M130X2	13		KM26	0.73
AHX3124	115	120	75	79	M130X2	12		KM26	0.94
AHX3224	115	120	90	94	M135X2	13		KM27	1.30
AH24024	115	120	73	82	M125X2	13		KM25	0.70
AH24124	115	120	93	102	M130X2	13		KM26	1.00
