Products Bearings 6000 Series

6000 Series

Bearing No.	Boundary Dimensions（mm)				Basic Load Rating		Balls		Limiting Speed		Net Weight
	Boundary Dimensions（mm)				Basic Load Rating		Balls		Limiting Speed		Net Weight
	d	D	B	Chamfer	Cr(KN)	Cor(KN)	Qty	Size	Grease	Oil	Kgs
604	4	12	4	0.2	0.97	0.36	6	2.381	43000	51000	0.002
605	5	14	5	0.2	1.33	0.505	6	3.175	39000	46000	0.0035
606	6	17	6	0.3	2.19	0.865	7	3.5	30000	38000	0.006
607	7	19	6	0.3	2.24	0.91	6	3.969	28000	36000	0.008
608	8	22	7	0.3	3.35	1.4	7	3.969	26000	34000	0.012
609	9	24	7	0.3	3.4	1.45	7	3.969	22000	30000	0.014
6000	10	26	7	0.3	4.55	1.96	7	4.763	20000	28000	0.019
6001	12	28	7	0.3	5.1	2.39	8	4.763	19000	26000	0.021
6002	15	32	9	0.3	5.6	2.84	9	4.763	18000	24000	0.03
6003	17	35	10	0.3	6.8	3.35	8	6.747	17000	22000	0.039
6004	20	42	12	0.6	9.4	5.05	8	7.938	15000	19000	0.069
6005	25	47	12	0.6	10.1	5.85	9	7.938	13000	17000	0.08
6006	30	55	13	1	13.2	8.3	9	9.525	12000	15000	0.116
6007	35	62	14	1	16	0.3	9	11.112	10000	13000	0.155
6008	40	68	15	11	16.8	11.5	9	12	8000	11000	0.185
6009	45	75	16	1	21	15.1	10	12	7200	9000	0.231
6010	50	80	16	1	22	16.3			6500	10000	0.248
6011	55	90	18	1.1	31.5	18.4			7500	9000	0.384
6012	60	95	18	1.1	30	23			6700	8000	0.426
6013	65	100	18	1.1	32	25			6300	7500	0.428
6014	70	110	20	1.1	38	31			6000	7000	0.62
6015	75	115	20	1.1	38	31			5600	6700	0.63
6016	80	125	22	1.1	47.5	40			5300	6300	0.86
6017	85	130	22	1.1	47.5	40			5000	6000	0.935
6018	90	140	24	1.5	58.5	50			4800	5600	1.16
6019	95	145	24	1.5	78.5	54			4500	5300	1.14
6020	100	150	24	1.5	57.5	56.5			4300	5000	1.17
6021	105	160	26	2	73	65.5			4000	4800	1.62
6022	110	170	28	2	82	73.5			3800	4500	2.09
6024	120	180	28	2	85.5	80			3400	4000	2.21
6026	130	200	33	2	101	94			3200	3800	3.29
6028	140	210	33	2	106	102			3000	3600	3.25
6030	150	225	35	2.1	131	125			2600	3200	4.14
6032	160	240	38	2.1	143	138			2400	3000	5.63
6034	170	260	42	2.1	170	171			2200	2800	6.78
6038	190	290	46	2.1	193.5	204			2000	2600	9.58
6040	200	310	51	2.1	222	245			1900	2400	11.7
6044	220	340	56	3	245	293			1800	2200	15.6
6044M	220	340	56	3	245	293			1800	2200	18.8
6048M	240	360	56	3	255	315			1700	2000	20.7
6052M	260	400	65	4	294	375			1500	1800	28.8
6056	280	420	65	4	305	405			1400	1700	32.2
6060	300	460	74	4	340	480			1200	1500	48.4
6064	320	480	74	4	355	510			1100	1400	50.3
